Example 2
<TOOLTYPECONFIGURATION>
<DELETE_TOOLTYPE>
<TOOLTYPE_110 />
</DELETE_TOOLTYPE>
</TOOLTYPECONFIGURATION>
See also
General settings
(Page 230)
9.2.6 Configuring the "Additional Data" window
<MOREDATACONFIGURATION> tag
The entries used for configuring the "Additional Data" window are located in the
<MOREDATACONFIGURATION>
tag. Various data items can be displayed for each tool type
in a number of rows and columns. Each data item to be displayed is specified by entering a
list parameter:
Tool parameter identifiers (Page 240)
Cutting parameter identifiers (Page 242)
Monitoring parameter identifiers (Page 244)
A brief description of the parameter (ShortText) then appears in the window with the value
itself beside it. Configuring list parameters (Page 249).
If another description text is required in the "More Data" window, a text can also be entered in
a row or column. In the window, the width of the text is made to conform to that of the brief
description and value of a parameter.
Any number of rows and columns can be created. A scrollbar appears when the window
reaches a certain size.
Entries Meaning
TOOLTYPE_XXX Number of the tool type.
See example: Tool type 111 = Ball end mill (tapered die-sinking cutter).
ROWX_COLY Particular rowX_columnY.
If there is no entry after rowX and columnY, this field remains blank.
See example: In the "More Data" window, the first row is blank.
Tool management
9.2 Configuring the user interface
SINUMERIK Operate
Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3 257
