Siemens SINUMERIK 828D Commissioning Manual

DRIVE-CLiQ interface Connection to
X202 Motor encoder for feedrate 2nd expansion axis (via Sensor Module)
Double Motor Module:
X200 X101 of the PPU
X201 Remains empty
X202 Motor encoder for feedrate 1st expansion axis
X203 Motor encoder for feedrate 2nd expansion axis
1)
Remains empty if only one Single Motor Module is used.
Assignment of the DRIVE-CLiQ
interfaces on the DMx20 to assign a direct measuring system
to the feed axes:
DRIVE-CLiQ interface Connection to
X500 X501 of the TM54F
X102 of the PPU (if a TM54F is not being used)
X501 Direct encoder, feedrate 1 at the S120 Combi
X502 Direct encoder, feedrate 2 at the S120 Combi
X503 Direct encoder, feedrate 3 on the S120 Combi
(only
for S120 Combi
with four axes, remains empty for S120 Combi
with three axes)
X504 Feedrate 1st expansion axis at the Motor Module
X505 Feedrate 2nd expansion axis at the Motor Module
Assignment of the DRIVE-CLiQ interfaces on the TM54F:
DRIVE-CLiQ interface Connection to
X500 X102 of the control (PPU)
X501 X500 of the DMx20: Without a DMx20, this interface remains empty.
5.4.2 Topology rules for S120 Booksize
Introduction
The following rules apply for wiring components with DRIVE-CLiQ. A distinction is made
between DRIVE-CLiQ rules which must always
be observed, and recommended rules which,
when observed, do not require any subsequent changes to the topology when expansions are
made.
The maximum number of DRIVE-CLiQ components and the possible wiring form depend on
the following points:
● The binding DRIVE-CLiQ wiring rules
● The number and type of activated drives and functions on the respective Control Unit
● The computing power of the respective Control Unit
● The set processing and communication cycles
Commissioning the drive
5.4 Topology rules for DRIVE-CLiQ
CNC commissioning
140 Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3
