<data name = "$MC_AXCONF_MACHAX_USED[4]">5</data>
<data name = "drive/dc/p971[DO5]">1</data>
<while>
<condition> "drive/dc/p971[DO5]" !=0 </condition>
<while>
<control_reset resetnc ="true" resetdrive = "true"/>
</SET_ACTIVE>
<SET_INACTIVE>
<data name = "drive/dc/p105[DO5]">0</data>
<data name = "$MC_AXCONF_MACHAX_USED[4]">0</data>
<data name = "drive/dc/p971[DO5]">1</data>
</while>
<condition> "drive/dc/p971[DO5]" !=0 </condition>
</while>
<control_reset resetnc ="true" resetdrive = "true"/>
</SET_INACTIVE>
</DEVICE>
Activating the PLC-controlled device
The device is activated and deactivated by the user program using bit memory 100.0.
<AGM>
<OPTION_MD NAME= "$MN_USER_DATA_INT[0]" />
<DEVICE>
<LIST_ID>1</LIST_ID>
<NAME> "PLC Device" </NAME>
<SET_ACTIVE>
<SET_ACTIVE>
<DATA NAME= "PLC/M100.0"> 1 </DATA>
</SET_ACTIVE>
<SET_INACTIVE>
<DATA NAME= "PLC/M100.0"> 0 </DATA>
</SET_INACTIVE>
</DEVICE>
</AGM>
Easy Extend
8.6 Examples
CNC commissioning
250 Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3
