Rockwell Automation MagneMotion MagneMover LITE User Manual

Design Guidelines
Transport System Configuration
MagneMover LITE User Manual 139
Rockwell Automation Publication MMI-UM002F-EN-P - October 2022
Transport System Configuration
All examples that are provided are for horizontal track layouts unless otherwise specified. The
motor with puck is shown in Figure 3-6.
Straight Track Configuration
Figure 3-64: Straight Track Configuration
• Node types at the beginning of a path: Simple, Relay, Terminus, Gateway.
• Node types at the end of a path: Relay, Terminus, Gateway.
Rails
MM LITE Straight Motor
Top View
Motor Gap
