Specifications and Site Requirements
Mechanical Specifications
196 MagneMotion
Rockwell Automation Publication MMI-UM002F-EN-P - October 2022
Figure 4-47: Precision Rail Straight, No Joint, Spine Plate, Mechanical Drawing
Figure 4-48: Precision Rail Straight, With Joint, Spine Plate, Mechanical Drawing
0
0
10.00
25.00
2X 55.00
85.00
100.00
110.0
4X 5.62
26.63
50.63
68.00
2X 125.0°
2X 145.0°
6X R4
[0.25]
6.35
All Dimensions in Millimeters
700-1622-02
0
0
2X 5.62
26.63
50.63
68.00
2X 54.98
64.98
73.58
124.98
132.0
141.5°
125.0°
[0.25]
6.35
All Dimensions in Millimeters
700-1622-05
