Rockwell Automation MagneMotion MagneMover LITE User Manual

Specifications and Site Requirements
Mechanical Specifications
178 MagneMotion
Rockwell Automation Publication MMI-UM002F-EN-P - October 2022
Standard Motor Mount Bracket
Figure 4-31: Standard Motor Mount Bracket Mechanical Drawing
Exposed Materials
• 6063-T5 AL, Anodized per MIL-A-8625F, Type II, Class 2.
• 304 Stainless Steel.
C
L
46.98
1.850
9.00[0.354] THRU
.625
15.88
3.200
81.3
±.0053.150
±0.1380.00
13.95
.549
±0.05
±.002
80.0
3.150
2.03
.080
2X 90°±1°
31.8
1.250
6.50 THRU
.256
.625
15.88
INSERT, TANGED, HLCL,
SLF-LKG, Ø5mm [Ø0.2in] X 5.00mm [0.200in] L
All Dimensions in Millimeters [Inches]
700-1427-00
