• Center Plate, Puck, Ribs, G5, ML.
• Replaceable Ski, ML Puck (2X).
• Spacer, Magnet Array, ML-PL (2X).
• Strip, Protective, Puck Bottom, Wide, UHMW (Optional).
• Isopropyl Alcohol.
• Torque wrench with the following bits:
• 2.5 mm Hex.
Procedure
Figure 7-48: Remove Precision Locator Pallet from Magnet Assembly
M4 x 20 mm Screw
(2X)
Magnet Assembly
Pallet
Center Plate
Protective Strip
Threaded Standoff
Ski
Glue Dot
Preload Spacer
M4 x 8 mm Screw
(2X)
(2X)
Spacer
(2X)
