Installation
Transport System Installation
MagneMover LITE User Manual 273
Rockwell Automation Publication MMI-UM002F-EN-P - October 2022
• For an NC-12 node controller, connect from a dedicated standard network
switch to ETHERNET (auto-MDIX and auto-negotiation are supported).
Route the cable so it is shielded from damage and can be easily accessed for
service.
• For an NC LITE node controller, connect from a network switch to LAN
(auto-MDIX and auto-negotiation are supported). Route the cable so it is
shielded from damage and can be easily accessed for service.
• When supplying power to the NC LITE through PoE, connect from a
dedicated network switch with +18V DC PoE.
• When supplying power directly to the NC LITE, connect from a dedi-
cated standard network switch.
2. Bundle and dress all cables (use nylon cable-ties) as required to make sure of clean
cable routing.
3. See Facilities Connections on page 302 for external network connections.
Digital I/O
If node controllers with digital I/O are being used, wiring for discrete digital inputs and out-
puts can be connected to the node controllers and used for E-stops, interlocks, light stacks, and
general-purpose I/O. See the Node Controller Hardware User Manual, MMI-UM013, for the
digital I/O connection locations and wiring diagrams.
NOTICE The NC-12 node controller does not support
Power over Ethernet (PoE). Never connect
these node controllers to a PoE network as
damage to internal components can result.
