Installation
Unpacking and Inspection
238 MagneMotion
Rockwell Automation Publication MMI-UM002F-EN-P - October 2022
Unpacking and Inspection
The MagneMover LITE transport system components are shipped in separate packages. Open
each package carefully following the steps that are provided in Unpacking and Moving on
page 239; inspect and verify the contents against the shipping documents. Report any damage
immediately to the shipper and to MagneMotion
®
.
One set of shipping documents is attached to the outside of the main shipping crate for easy
access.
NOTE: The number and contents of the shipping packages depends on the items that are pur-
chased and their configuration (that is, shipped as components or shipped as a sys-
tem). See the shipping documents for the exact contents. The checklist in Table 5-1
is provided for reference only.
Table 5-1: MagneMover LITE Component Packing Checklist Reference
Package Contents
MagneMover LITE Motors MagneMover LITE linear synchronous motors.
MagneMover LITE Stands Modular aluminum stand system configured for the motors.
Includes beam sections, motor mounts, and cable chase covers.
MagneMover LITE Pucks
or magnet arrays
MagneMover LITE pucks/magnet arrays for use as the LSM sec-
ondary to move material on the transport system.
Node Controllers MagneMotion node controllers for managing the nodes in the
transport system.
Power Supplies Power supplies to provide logic and propulsion power to the Mag-
neMover LITE motors.
Installation Kit • Miscellaneous hardware.
• Cables.
• User manuals, drawings, and so on.
Precision Rail Option • Straight and curve rails.
• Post and post/mount assemblies.
• Spine plates.
• Vehicles.
Precision Locator Option • Precision locator.
• Locator stand.
• Adjustable motor mounts.
