Installation
Option Installation
MagneMover LITE User Manual 299
Rockwell Automation Publication MMI-UM002F-EN-P - October 2022
3. Verify proper clearances between the puck and the precision locator and adjust the set
screws on the motor mount as required.
With the puck manually pinned into position on the stand (press down on both
arms simultaneously to secure the puck), verify 0.13 mm [0.005 in] clearance
between the top of the rail and the skis on the pallet.
With the puck manually pinned into position on the stand, verify 0.13 mm
[0.005 in] clearance between the bottom of the rail and the center plate on the
puck.
With the puck manually pinned into position on the stand, verify 0.13 mm
[0.005 in] between the puck lobes and the side-surface of the rail.
With the puck out of the station, verify that when the arm is in the down
(pinned) the position the pin is below the pallet surface.
With the puck out of the station, verify that when the arm is in the up position
the pallet clears the pins.
4. Tighten the locknuts on the motor mount to 10.2 N•m [90 in•lb].
5. Apply Loctite 243 to the M6 x 12 mm screws that were removed from the back plate
and replace the back plate on the stand. Tighten the screws to 5 N•m [45 in•lb] with a
5 mm Hex wrench.
The Loctite must cure for 2 hours at 22° C [72° F] before using the transport system.
6. Adjust the position of the locator stand as required.
Make sure of proper alignment between the bushings on the puck and the pins
on the precision locator.
With the puck manually pinned into position on the stand, verify proper access
to the pallet by the remote equipment.
7. Tighten the M8 bolts that secure the stand ribs to the beam to 26 N•m [230 in•lb].
Install the Pneumatic Controls
Install the pneumatic fittings on the cylinder of the precision locator before the locator is
mounted on the stand to provide ease of access (see Install the Precision Locators on the
Stands).
PNEUMATIC HAZARD
Do not turn on the pneumatic system until all installation
procedures have been completed.
