428 MagneMotion
Rockwell Automation Publication MMI-UM002F-EN-P - October 2022
Replace Precision Rail Vehicles
Precision rail vehicles must be replaced if they become damaged or worn. Additionally, vehi-
cles can be added to, or removed from, the transport system if the quantity of vehicles in use is
not correct. If the transport system does not contain an open end that can be used to insert or
remove the vehicles, use the following procedure to replace the vehicles.
Required Tools and Equipment
• Open-end wrench, 13 mm, thin.
• Socket wrench, 13 mm.
• Torque wrench (0.9…26 N•m [8…230 in•lb] range) with the following socket:
•13mm Hex.
MAGNETIC FIELD HAZARD: Strong magnets in use.
To avoid severe injury, people with pacemakers and other
medical electronic implants must stay away from the magnet
array on the vehicles (pucks).
PINCH/CRUSH HAZARD: Strong magnets in use.
To avoid injury from strong magnetic attractive forces:
• Handle only one vehicle (puck) or magnet array at a time.
• Do not place any body parts (for example, fingers)
between a magnet array and any ferrous material or
another magnet array.
• Vehicles (pucks) and magnet arrays not being used must
be secured individually in isolated packaging.
NOTICE Strong magnets in use.
To avoid damage to watches, instruments, electronics, and
magnetic media, keep metal tools, metal objects, magnetic
media (for example, memory disks/chips, credit cards, and
tapes) and electronics away from the magnet arrays.
