Machine mode of operation | Pocket table setup
4
HEIDENHAIN | MANUALplus 620 | User's Manual | 12/2017
109
Machine with turret
Press the turret list soft key to open the list of the current turret
assignment. There is a place in the table for every tool holder of the
turret (and possibly multifix). During setup, each tool (ID number)
is assigned to a tool holder. In the turret list, multipoint tools are
displayed with all cutting edges.
The turret list can be set up through the TSF menu or directly from
the cycle dialogs in Teach-in submode:
T: Tool number – turret pocket number
ID: ID no. – Tool name (max. 16 characters)
The tool name is entered automatically.
Cursor in the TSF menu in the T input field:
Press the Turret list soft key
After opening, the turret list can be edited.
Cursor in the TSF menu in the ID input field:
Press the Tool list soft key
The tool list is also opened in addition to the
turret list.
The turret can be populated with tools from the
list.
In the Teach-in cycle, you program the turret pocket as a T number.
The tool ID number is automatically entered in ID if a tool is
assigned to the pocket.
Refer to your machine manual.
The turret, magazine and multifix tool systems can be
used together on one machine.
The machine tool builder defines the number of the
multifix pocket.
