Introduction and fundamentals | Features
1
48
HEIDENHAIN | MANUALplus 620 | User's Manual | 12/2017
Tool system
Database for 250 tools, optionally 999 tools
Description can be entered for every tool
Optional support of multipoint tools (tools with multiple
reference points or multiple cutting edges)
Turret or multifix system
Optional tool magazine
Technology database
Cutting data is entered in the cycle or in the UNIT as default
values
9 workpiece-material/tool-material combinations (144 entries)
Optionally 62 workpiece-material/tool-material combinations
(992 entries)
Interpolation
Straight line: in 2 principal axes (max. ±100 m)
Circular: in 2 axes (radius max. 999 m)
C axis: Interpolation in the linear axes X and Z with the C axis
Y axis: Linear or circular interpolation of two axes in the given
plane. The respective third axis can simultaneously perform
linear interpolation.
G17: XY plane
G18: XZ plane
G19: YZ plane
B axis: Drilling, boring and milling operations in oblique planes
