Machine mode of operation | Pocket table setup
4
HEIDENHAIN | MANUALplus 620 | User's Manual | 12/2017
117
Tool call
Refer to your machine manual.
This function is also available on machines with a tool
magazine.
The control will then use the magazine list instead of the
turret list.
Parameters for calling the tool
T is the identification letter for the tool holder.
Refer to your machine manual.
The designation of the tool pockets may vary depending
on the machine.
Each tool holder of a tool carrier has a unique T number
in the working space.
ID designates the tool ID number.
The ID number of a tool is defined when you create a
tool in Tool editor mode of operation. Each tool has a
unique ID.
Variants of the tool call
A tool holder, e.g. Multifix
The tool is called by its ID. The tool pocket number T is always
1. The control does not maintain a turret list.
Multiple tool holders, e.g. turret
The tool is called by T (turret pocket number). The ID number ID
is shown and automatically entered in the dialogs. The control
maintains a turret list.
In the turret list, multipoint tools are displayed with all cutting
edges.
You enter the parameters for calling the tool in the TSF dialog in
Machine mode of operation. In Teach-in submode and smart.Turn
mode of operation, T and ID are cycle parameters.
If a T number is entered in the TSF dialog with an ID
number that is not defined in the turret list, then the
turret list will be changed accordingly. The existing turret
list will be overwritten.
