Machine mode of operation | Program management
4
HEIDENHAIN | MANUALplus 620 | User's Manual | 12/2017
167
Project management
You can make your own project folder in the project management
so that you can centrally manage associated files. When you
create a project, a new folder is set up with the corresponding
subfolder structure in the TNC:\Project\ directory. You can save
your programs, contours and drawings to the subfolders.
The Project soft key activates the project management. The
control shows you all existing projects in a tree structure. The
control also opens a soft-key menu in the project management that
allows you to create, select and manage projects. To reselect the
standard directory of the control, select the TNC:\nc_prog folder
and press the Select std. directory soft key.
Soft keys project
Create new project
Copy marked project
Delete marked project following confirma-
tion prompt
Rename marked project
Open standard directory
Open machine tool builder programs
Select marked project
Select standard directory
You can select any project names. The subfolders (dxf,
gti, gtz, ncps and Pictures) have predefined names that
must not be changed.
All existing project folders are displayed in the project
management. Use the file manager to switch between
subfolders.
