Teach-in | Single cut cycles
5
HEIDENHAIN | MANUALplus 620 | User's Manual | 12/2017
183
5.3 Single cut cycles
Menu item Meaning
In the single cut cycles you position the tool
in rapid traverse, perform linear or circular
cuts, machine chamfers or rounding arcs,
and enter M functions.
Menu item Single cut cycles
Rapid positioning
Tool change point
Linear mach. longit./Linear mach. transv.
Single longitudinal/transverse cut
Linear machining in angle Single oblique
cut
Circular machining Single circular cut (for
cutting direction, see menu item)
Cham Machine a chamfer
Round. Machine a rounding
Call an M function
