Tool and technology database | Tool data
8
HEIDENHAIN | MANUALplus 620 | User's Manual | 12/2017
593
Knurling tool
Press the New tool soft key
Press the Special tool soft key
Press the Knurling tool soft key
The help graphics illustrate the dimensions of the tools.
Special parameters for knurling tools:
SL: Cutting length
EW: Setting angle
SB: Cutting width
DN: Tool width
SD: Shank diameter
Further tool parameters:
Further information: "General tool parameters", Page 576
