Tables and overviews | Thread
10
678
HEIDENHAIN | MANUALplus 620 | User's Manual | 12/2017
10.1 Thread
Thread parameters
To determine the thread parameters, the control uses the following
table.
Where:
F: Thread pitch is calculated from the diameter, depending on
the thread type, where an asterisk * is given
Further information: "Thread", Page 678
P: Thread depth
R: Thread width
A: Thread angle, left
W: Thread angle, right
Calculation formula: Kb = 0.26384 * F – 0.1 * # F
Thread backlash ac (depending on the Thread pitch):
Thread pitch <= 1 : ac = 0.15
Thread pitch <= 2 : ac = 0.25
Thread pitch <= 6 : ac = 0.5
Thread pitch <= 13 : ac = 1
Sort of thread Q F P R A W
Q = 1 Metric ISO fine-pitch thread
External –
0.61343 * F F
30° 30°
Internal –
0.54127 * F F
30° 30°
Q = 2 Metric ISO thread
External *
0.61343 * F F
30° 30°
Internal *
0.54127 * F F
30° 30°
Q = 3 Metric ISO tapered thread
External –
0.61343 * F F
30° 30°
Q = 4 Metric ISO tapered fine-pitch thread
–
0.61343 * F F
30° 30°
Q = 5 Metric ISO trapezoid thread
External –
0.5 * F + ac 0.633 * F
15° 15°
Internal –
0.5 * F + ac 0.633 * F
15° 15°
Q = 6 Flat metric trapezoid thread
External –
0.3 * F + ac 0.527 * F
15° 15°
Internal –
0.3 * F + ac 0.527 * F
15° 15°
Q = 7 Metric buttress thread
External –
0.86777 * F 0.73616 * F
3° 30°
Internal –
0.75 * F F – Kb
30° 3°
Q = 8 Cylindrical round thread
External *
0.5 * F F
15° 15°
Internal *
0.5 * F F
15° 15°
Q = 9 Cylindrical Whitworth thread
External *
0.64033 * F F
27.5° 27.5°
Internal *
0.64033 * F F
27.5° 27.5°
Q = 10 Tapered Whitworth thread
External *
0.640327 * F F
27.5° 27.5°
Q = 11 Whitworth pipe thread
External *
0.640327 * F F
27.5° 27.5°
Internal *
0.640327 * F F
27.5° 27.5°
Q = 12 Nonstandard thread
– – – – –
Q = 13 UNC US coarse thread
External *
0.61343 * F F
30° 30°
Internal *
0.54127 * F F
30° 30°
