Operating the Touchscreen | Gestures
3
86
HEIDENHAIN | MANUALplus 620 | User's Manual | 12/2017
Symbol Gesture Meaning
Two-finger drag A combination of long-press and then swipe, moving
two fingers in parallel over the screen when the start-
ing point is clearly defined
Spread Two fingers long-press and move away from each
other
Pinch Two fingers move toward each other
Navigating in the table and NC programs
You can navigate in an NC program or a table as follows:
Symbol Gesture Function
Tap Mark the NC block or table line
Stop scrolling
Double tap Activate the table line
Edit NC block or unit
Swipe Scroll through the NC program or table
