Machine mode of operation | Manual operation
4
HEIDENHAIN | MANUALplus 620 | User's Manual | 12/2017
139
Handwheel operation
Further information: Refer to your machine manual
Manual direction keys
With the manual direction keys, you can move the axes at the
programmed feed rate or at rapid traverse. Enter the feed rate in
the TSF dialog.
Feed rate
If the spindle is rotating: Feed per revolution
[mm/rev]
If the spindle is not rotating: Feed per minute
[m/min]
Feed rate at rapid traverse : Feed per minute [m/
min]
Teach-in cycles in Machine mode of operation
Set the spindle speed
Set the feed rate
Insert the tool, define the tool number and check the tool data
(T0 is not permitted)
Approach the cycle start point
Select the cycle and enter the cycle parameters
Graphically check the cycle run
Run the cycle
The entries last made in a cycle dialog remain in
memory until a new cycle is selected.
