Machine mode of operation | Pocket table setup
4
HEIDENHAIN | MANUALplus 620 | User's Manual | 12/2017
115
Editing the magazine list
For machines with tool magazines, the magazine list indicates the
current assignment of the existing magazines and tool carriers
in the working space. The magazine list can be edited via the
TSF menu.
Loading the magazine:
Select Set T, S, F (can only be selected in
Machine mode of operation)
Select Load magazine
Activate the tool list with the Load the pocket
soft key
Select the tool
Select the tool with the Load tool soft key
Transfer the tool to the magazine list with the
Save soft key
Changing the tool:
Select Set T, S, F (can only be selected in
Machine mode of operation)
Select Tool change
Select the tool with the Magazine list soft key
Alternative: Enter the tool ID number directly
Change the tool with the Save soft key
