Machine mode of operation | Machine setup
4
128
HEIDENHAIN | MANUALplus 620 | User's Manual | 12/2017
Configuring the HR 550FS wireless handwheel
Application
Select the Set up wireless handwheel menu item to configure
the HR 550FS wireless handwheel. The following functions are
available:
Assigning the handwheel to a specific handwheel holder
Setting the transmission channel
Analyzing the frequency spectrum for determining the optimum
transmission channel
Select transmitter power
Statistical information on the transmission quality
Set up wireless handwheel:
Select Setup
Select Service
Select Set up wireless handwheel
Assigning the handwheel to a specific handwheel holder
Make sure that the handwheel holder is connected to the
control hardware.
Place the wireless handwheel you want to assign to the
handwheel holder in the handwheel holder
Select the Setup menu item
Select the Service menu item
Select the Set up wireless handwheel menu item
Click the Connect HW button
The control saves the serial number of the inserted wireless
handwheel and shows it in the configuration window on the
left next to the Connect HW button.
To save the configuration and exit the configuration menu,
press the END button
