Machine mode of operation | Pocket table setup
4
HEIDENHAIN | MANUALplus 620 | User's Manual | 12/2017
111
Filling the turret list with contents from the tool list
The turret list indicates the current assignment of the tool carrier.
The turret list can be set up through the TSF menu or directly from
the cycle dialogs in Teach-in submode.
Look at the entries in the tool list in order to move entries from
the list into the turret assignment list. The control displays the tool
list in the lower area of the screen. The arrow keys are active in
this list. You can move the cursor directly to a tool ID number by
entering the first few letters or digits of the ID number.
Opening the turret list:
Select Set T, S, F (can only be selected in
Machine mode of operation)
Alternative: Initiate the cycle dialog
Press the Tool list soft key to activate the turret
assignment list and the tool list
Adapt the turret assignment list
Transferring tools from the database:
Select the position in the turret assignment list
Select and sort the entries in the tool database
Use the arrow keys to select the entry in the tool
database
Load the selected tool into the turret assignment
list
