Tool and technology database | Tool data
8
HEIDENHAIN | MANUALplus 620 | User's Manual | 12/2017
589
Standard milling tools
Press the New tool soft key
Press the Milling tool soft key
The help graphics illustrate the dimensions of the tools.
Special parameters for standard milling tools:
DV: Milling diameter
AZ: No. of teeth
DD: Special corr.
SL: Cutting length
R2: Tool radius 2
DR2: Tool radius 2 oversize
Further tool parameters:
Further information: "General tool parameters", Page 576
For milling operations at constant cutting speed,
Cutter diameter DV is used to calculate the spindle
speed
For G193 Feed per tooth, the No. of teeth AZ
parameter is evaluated
