ICP programming | Contours in the YZ plane
6
HEIDENHAIN | MANUALplus 620 | User's Manual | 12/2017
511
TURN PLUS attributes
In the TURN PLUS attributes, you can define settings for the
automatic working plan generation (AWG) submode.
Parameters for defining the starting point:
HC: Milling/drilling attribute
1: Contour milling
2: Pocket milling
3: Area milling
4: Deburring
5: Engraving
6: Contour + deburring
7: Pocket + deburring
14: Do not machine
QF: Cutter position
0: On the contour
1: Inside / left
2: Outside / right
HF: Direction
0: Up-cut
1: Climb
DF: Milling diameter
WF: Angle of chamfer
BR: Chamfer width
RB: Return plane
