Teach-in | Single cut cycles
5
196
HEIDENHAIN | MANUALplus 620 | User's Manual | 12/2017
M functions
Machine commands (M functions) are not executed until NC start
has been pressed. With the M list soft key you can open an
overview of the available M functions. For the meaning of the M
functions, refer to your machine manual.
M function:
Select Single cuts
Select M function
Enter the number of the M function
Conclude entry
Press the NC start key
Spindle stop M19 (spindle positioning):
Select Single cuts
Select M function
Activate M19
Enter the stopping angle
Conclude entry
Press the NC start key
