Tool and technology database | Tool data
8
592
HEIDENHAIN | MANUALplus 620 | User's Manual | 12/2017
Burr cutters
Press the New tool soft key
Press the Special tool soft key
Press the special milling tools soft key
Press the Thin millg. cutter soft key
The help graphics illustrate the dimensions of the tools.
Special parameters for burr cutters:
DV: Milling diameter
AZ: No. of teeth
SL: Cutting length
FW: Cutter angle
DD: Special corr.
Further tool parameters:
Further information: "General tool parameters", Page 576
For milling operations at constant cutting speed,
Cutter diameter DV is used to calculate the spindle
speed
For G193 Feed per tooth, the No. of teeth AZ
parameter is evaluated
