Basics of operation | Program types
2
70
HEIDENHAIN | MANUALplus 620 | User's Manual | 12/2017
2.5 Program types
The control supports the following programs/contours:
Teach-in programs (cycle programs) are used in the Teach-in
submode
smart.Turn and DIN main programs are written in the
smart.Turn mode of operation
DIN subprograms are written in the smart.Turn operating
mode and are used in cycle programs and smart.Turn main
programs
ICP contours are generated in Machine operating mode or in
Teach-in submode.
The file name extension depends on the contour described.
In smart.Turn operating mode, the contours are saved directly in
the main program.
Program type Folder Extension
Teach-in programs
(cycle programs)
nc_prog\gtz *.gmz
smart.Turn and DIN
main programs
nc_prog\ncps *.nc
DIN subprograms
nc_prog\ncps *.ncs
ICP contours
nc_prog\gti
Turning contours
Contours of
workpiece blanks
Contours on face
Lateral surface
contours
*.gmi
*.gmr
*.gms
*.gmm
