Tool and technology database | Tool data
8
590
HEIDENHAIN | MANUALplus 620 | User's Manual | 12/2017
Thread milling tools
Press the New tool soft key
Press the Special tool soft key
Press the Milling tool soft key
Press the Thread cutter soft key
The help graphics illustrate the dimensions of the tools.
Special parameters for thread milling tools:
DV: Milling diameter
AZ: No. of teeth
FB: Cutter width/height
HG: Thread pitch
DD: Special corr.
Further tool parameters:
Further information: "General tool parameters", Page 576
For milling operations at constant cutting speed,
Cutter diameter DV is used to calculate the spindle
speed
For G193 Feed per tooth, the No. of teeth AZ
parameter is evaluated
