Organization mode of operation | Transfer submode
9
664
HEIDENHAIN | MANUALplus 620 | User's Manual | 12/2017
Transferring tool data
Tool data is backed up and restored in the following steps:
Creating a tool backup: The parameters are archived in ZIP
files and stored in the control
Transmitting or receiving the tool backup files
Restoring tools: Restore the backup files into the active data of
the control (login required)
Tool selection
You can also create a tool backup without connecting to an external
storage device.
Creating a tool backup:
Select the Organization operating mode
Press the Transfer soft key (login required)
Press the Tools soft key
Soft keys for tool transfer
Soft key Meaning
Transmit all marked files from the control to
the remote station
Receive all files marked on the remote
station
Delete all marked files after a confirmation
prompt (login required)
Create a tool backup data record as a .zip file
Restore data from the selected backup data
record to the active control system (login
required)
Mark all files in the current window
Mark or unmark the file at the cursor
position and move the cursor down one
position
Select the ZIP or HTT file type. The tool data
can also be transferred directly as a HTT file
(e.g. from a tool presetter)
