Organization mode of operation | Transfer submode
9
656
HEIDENHAIN | MANUALplus 620 | User's Manual | 12/2017
USB connection
Establishing a USB connection:
Select the Organization operating mode
Connect the USB storage device to the USB
interface of the control
Press the Transfer soft key (login required)
Press the Connections soft key
Press the USB soft key
The control opens the USB dialog. In this dialog,
you can enter the settings for the connection
target
Use the soft keys to disconnect or reconnect
USB storage devices
In principle, it should be possible to connect most USB
devices to the control. It may happen that a USB device
is not identified correctly by the control, for example
when the cable between the control panel and the main
computer is very long. In such cases, use another USB
device.
Soft keys for USB connection
Soft key Meaning
Create a folder of the specified name on the
USB storage device
Disconnect the USB storage device and
prepare the device for removal
Allow access to files that have not been
properly saved in a project folder
Select the project folder that you selected
before with the arrow keys
Return to the Transfer soft-key menu
