6.16 Loading existing contours
Integrating cycle contours in smart.Turn mode of
operation
ICP contours that you have created for cycle programs can be
loaded in smart.Turn mode of operation. ICP converts the contours
into G codes and integrates them in the smart.Turn program. The
contour is now part of the smart.Turn program.
The ICP editor submode considers the type of contour. For
example, you can load a contour defined for the face only if you
have selected the face (C axis) in smart.Turn mode of operation.
Integrating a contour:
Activate the ICP editor submode
Press the Contour list soft key
The ICP editor submode opens the Select ICP
contours window
Press the Next file type soft key until the cycle
contours are displayed
Select the file
Load the selected file
Complete the contour, if necessary
Workpiece blank or finished part contour:
Complete or adapt the contour
C axis contour: Complete the reference data
Extension Group
*.gmi
Turning contours
*.gmr
Contours of workpiece blanks
*.gms
Milling contours on face
*.gmm
Milling contours on lateral
surface
