Overview of cycles | Drilling cycles
11
716
HEIDENHAIN | MANUALplus 620 | User's Manual | 12/2017
11.5 Drilling cycles
Drilling cycles Page
Overview Page 342
Drilling axial: For drilling single
holes and patterns
Page 342
Drilling radial: For drilling single
holes and patterns
Page 345
Deep drilling axial: For drilling
single holes and patterns
Page 347
Deep drilling radial: For drilling
single holes and patterns
Page 350
Tapping axial: For drilling single
holes and patterns
Page 353
Tapping radial: For drilling single
holes and patterns
Page 355
Thread Mill: For milling threads in
existing holes
Page 357
