Organization mode of operation | Transfer submode
9
HEIDENHAIN | MANUALplus 620 | User's Manual | 12/2017
657
Data transfer options
The control manages DIN programs, DIN subprograms, cycle
programs and ICP contours in different directories. When you
select Program group, the control automatically switches to the
applicable directory.
Parameters and tool data are stored under the file name entered
for backup name and saved to a ZIP file located in the para or tool
folder on the control. You can then send this backup file to a project
folder in the remote station.
If program files are opened in another operating
mode, they are not overwritten
You can transfer tool data and parameters only if no
program has been started in Program run submode
The following transfer functions are available:
Programs: Transmit and receive files
Parameter backup: Create, transmit, and receive parameter
backups
Parameter restore: Restore the parameter backup files
Tools backup: Create, transmit, and receive tool backups
Restore tools: Restore the tool backup files
Service data: Create and transmit service data
Make data backup: Save all data in a project folder
Free external: Freely select program files on a USB storage
device
Misc. functions: Import cycle programs and DIN programs
from the MANUALplus 4110 and import tool data from the CNC
PILOT 4290
