6.10 Contour elements on lateral surface
With the contour elements of a lateral surface you can create
complex milling contours.
In Teach-in submode: Contours for radial ICP milling cycles
In smart.Turn mode of operation: Contours for machining with
the C axis
Enter the dimensions of the lateral surface contour elements in
Cartesian or polar coordinates. You can use the linear dimension as
an alternative to the angular dimension. You can switch between
them by soft key.
The linear dimension is essentially the unrolled surface
at the reference diameter.
For lateral surface contours, the reference diameter
is specified in the cycle. The linear dimensions of all
subsequent contour elements are referenced to this
diameter
When called from smart.Turn mode of operation,
the reference diameter in the reference data is
requested
Soft keys for polar coordinates
Switch the field from linear dimensions to
entry of the angle C
Switch the field to entering the polar dimen-
sion P
