List operations
Cycle programs, DIN programs, tool lists, etc. are displayed as lists.
You can scroll through a list with the arrow keys to check data or
to highlight elements for operations like deleting, copying, editing,
etc.
Alphabetic keyboard
You enter letters and special characters with the screen keypad or
(if available) with a PC keyboard connected over the USB port.
Entering text with the screen keyboard
Press the Alphabetic keyboard soft key or the GOTO key to
enter text.
The control opens the Text input window.
Enter the desired character or special character by pressing the
numerical key multiple times.
Use the abc/ABC soft key to select upper or lower case.
Wait until the selected character appears in the input field.
Then, enter the next character.
Use the OK soft key to transfer the text into the open dialog
field.
To delete individual characters, use the BACKSPACE soft key.
