Tool and technology database | Tool editor mode of operation
8
HEIDENHAIN | MANUALplus 620 | User's Manual | 12/2017
563
Editing the tool data
Creating a new tool:
Press the New tool soft key
Select the tool type
The control opens the input window
Specify the tool orientation
Enter further parameters
Assign the tool ID number (1 to 16 places,
alphanumeric)
Assign a tool text
Further information: "Tool texts", Page 565
The control does not show the help graphics for
individual parameters until the tool orientation is known.
Tool organization soft keys
Open the following type selection for creat-
ing a new tool
Switch to the soft-key row with the special
tools
Type selection for special drilling tools
Type selection for special milling tools
Type selection for handling systems and
touch probes
Open the dialog for the selected tool
Copy the selected tool and create a new tool
with the copied data
