HEIDENHAIN 548431-05 User Manual

Teach-in | Milling cycles
5
388
HEIDENHAIN | MANUALplus 620 | User's Manual | 12/2017
Milling direction for contour milling
Cycle type Cutting direction Direction of tool
rotation
MCRC Execution
Inside (JK=1) Up-cut milling (H=0)
Mx03 Right
Inside
Up-cut milling (H=0)
Mx04 Left
Inside
Climb milling (H=1)
Mx03 Left
Inside
Climb milling (H=1)
Mx04 Right
Outside (JK=2) Up-cut milling (H=0)
Mx03 Right
Outside
Up-cut milling (H=0)
Mx04 Left
Outside
Climb milling (H=1)
Mx03 Left
Outside
Climb milling (H=1)
Mx04 Right
Right (JK=2)
For open contours
without function.
Machining in direc-
tion of contour
definition
Without effect Right
Left (JK=1)
For open contours
without function.
Machining in direc-
tion of contour
definition
Without effect Left
