CONTROLLER BOARD
G338/G339 2
SM
1.2 CONTROLLER
BOARD
1.2.1 CONTROLLER
BOARD
LAYOUT
CN314
(F
AN Power Supply)
CN311
(Centronics I/F)
CN31
1 (NIB)
CN300
CN301
(128MB Memory)
(Option Me
mory)
(USB 2.
0)
(IEEE 1394 Firewire)
(802.1
1
b Wireless LAN)
CN30
3
Slot 2
(PS3)
CN3
02
Slot 1
(Printer Scanner DIMM
or Printer DIMM)
CN313
(Debug)
HDD
G338D999.
W
MF
1025
1027
