MFP OPTIONS: B064 SERIES
B064 Series/B140 Series/G126 1-100 SM
ACCESSORY CHECK
Check the accessories and their quantities against this list:
Description Q’ty
1. File Format Converter Board ................................................. 1
2. MLB bracket........................................................................... 1
3. MLB panel.............................................................................. 1
4. Screw M3 x 6......................................................................... 2
Installation Procedure
CAUTION
Unplug the main machine power code before you start this procedure.
Installing the Firmware
1. Remove the rear cover ( x 2).
2. Remove the controller cover ( x 10).
3. Turn on DIP SW2-1 on the controller board.
4. Install these firmware modules.
• RA2K Controller (System and Copy)
• Printer/Scanner
• NIB Netfile
5. Turn off DIP SW2-1 on the controller board.
6. Install these firmware modules.
• BCU
• LCDC
To Next Page
