SENSORS
B471 2
SM
1.2 SENSORS
Remove the tray (
1.1)
[A]: Bin
cover
[B]:
Tray sensor (
x 1)
[C]:
Tray overflow sensor (
x 1)
[D]:
Vertical transport sensor (
x 1)
•
Raise the pawl, then grip the bot
tom of the sensor to remove.
B471R003.W
MF
B471R104.
W
MF
[B]
[C]
[D]
[A]
863
865
