PCBS AND HDD
B064/B140 Series/G126
3-122
SM
3.12.5
PSU, PFC BOARDS
B064 Series
Rear lower cover (
3.3.5)
[A]:
Harness clamps (
x 3)
[B]: PSU
(
x 6,
x 13)
•
The PSU consists of two PCB’s.
[C]: PFC
(
x 4,
x 14)
B140 Series PSU
Rear covers (
3.3.5)
Controller box cover (
x 12)
[A]: PSU
(
x 5,
x 7)
B140R862.
W
MF
B140R703.
W
MF
[A]
[C]
[B]
[A]
295
297
