DEVELOPMENT
UNIT
SM
3-53
B06
4 Series/B140 Series/G126
Replac
ement
Adjustment
3.7.7 DEVELOPMENT
MOTOR
[A]: Flywheel
(
x 3)
[B]:
Waste toner pump tube (
x 1,
x 1)
[C]: Drive
rod
•
Lift the toner pump tube to disengage t
he drive rod, pull out the rod, and
push the rubber tube aside.
[D]:
Development motor bracket (
x 3,
x 1)
[E]:
Development motor (
x 4)
B140R969.W
MF
B140R970.W
MF
[D]
[E]
[A]
[B]
[C]
226
228
