ADF (B140 SERIES/B064 SERIES)
SM 3-133 B064 Series/B140 Series/G126
Replacement
Adjustment
3.13.6 ADF CONTROL BOARD
ADF Rear cover ( 3.13.1)
[A]: ADF board ( x 2, x 14)
B140R873.WMF
[A]
