DRUM UNIT
B064 Series/B140 Series/G126
3-46
SM
3.6.17 OZONE
FILTERS
[A]:
Filter cover (
x 1)
•
The filter cover is on the back of
the machine.
[B]:
Ozone filter (top)
[C]:
Ozone filter (bottom)
3.6.18
OPTICS DUST FILTER
[A]: Filter
cover
[B]:
Optics dust filter
3.6.19
INTERNAL DUST FILTER
1.
Open the front door.
2.
Pull out the internal dust filter [A].
B140R956.
W
MF
B140R957.
W
MF
B140R958.
W
MF
[A]
[C]
[A]
[B]
[A]
[B]
219
221
