REPLACEMENT AND ADJUSTMENT
SM 5
B660
Z-Folding Unit
B660
3.3 FEED
MOTOR
1.
Pull the Z-folding mechanism
out of the unit, but not fully.
2. Remove:
(
3.2)
•
Left cover
•
Right cover
•
Back cover
[A]:
Motor cover (
x 3)
[B]:
Feed Motor (
x 2,
x 1, timing belt x 1)
Re-installation
Make sure that the motor cover
is below the leaf springs [C].
B660R102.
W
MF
[A]
[B]
[C]
998
