FEED UNIT AND PICK-UP ROLLER
B470 2
SM
1.2
FEED UNIT AND PICK-UP ROLLER
Open the feed cover.
[A]: Feed
unit
•
The unit is spring loaded. Push it to t
he right to release
it, then lift it out.
[B]:
Pick-up roller (
x 2, bushings x 2)
B470R002.W
MF
B470R003.
W
MF
[A]
[B]
845
847
