Ricoh 4051 Service Manual

ADF (B140 SERIES/B064 SERIES ONLY)
B064 Series/B140 Series/G126 6-20 SM
6.4.8 ORIGINAL SIZE DETECTION
[A]: Original width sensor 1
[B]: Original width sensor 2
[C]: Original width sensor 3
[D]: Original width sensor 4
[E]: B5 length sensor
[F]: A4 length sensor
[G]: LG length sensor
When the leading edge of the paper passes the skew correction sensor, the CPU
reads the outputs from the original width and length sensors.
Please refer to the table on the next page.
B140D914.WMF
[A]
[B]
[C]
[D]
[E]
[F]
[G]

Ricoh 4051 Specifications

General

Print Technology	Laser
Print Speed (Black)	40 ppm
Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	150, 000 pages
Duplex Printing	Yes
Mobile Printing	Yes
Copy Speed (Black)	40 cpm
Copy Resolution	600 x 600 dpi
Fax Speed	33.6 Kbps
Functionality	Copy, Print, Scan, Fax
Connectivity	Ethernet, USB
Scan Resolution	600 dpi
