JOGGER BOTTOM FENCE MOTOR(B674 ONLY)
B468/B469/B674 12
SM
1.12 JOGGER BOTTOM FENCE MOTOR(B674 ONLY)
1.
Open the front door and pull
out the stapler tray unit.
2.
Remove the jogger bot
tom fence motor [A] (
x 2, timing belt x 1,
x 1,
x 1).
B468R902.W
MF
[A]
800
802
