ADF (B140 SERIES/B064 SERIES)
B064/B140 Series/G126
3-128
SM
3.13 ADF (B140 SERIES/B064 SERIES)
3.13.1 ADF
COVERS
Open the feed cover [A] (
x 1,
x 2, ground wire x 1).
[B]:
Front cover (
x 2)
•
Press down on the tabs to remove.
[C]:
Rear cover (
x 2)
•
Press down on the tabs to remove.
B140R866.
W
MF
[A]
[B]
[C]
Rev. 05/2005
301
303
